Chapter 3 Front Panel Overview Front Panel Display
© 2012 Harmonic Inc. 35 ProView 7000 v.2.6, Rev. E
3.2.3 Edit Value Pages
Use Edit Value pages to edit parameter values. The parameter value can be a number or a
string.
Use the <left> and <right> arrow keys to select a digit and the <up> and <down> arrow keys
to change the value of the parameter. On the ProView 7100™ you can enter values using the
alphanumeric keypad. Press <ENTER> to confirm the change or <ESC> to revert to the original
value.
3.2.4 Radio Select Pages
Radio select pages display a list of items for selection (ƒ = currently active, ‚ = currently
inactive):
Use the <up> and <down> arrow keys to move between the items and press <ENTER> to
select the required option. After pressing <ENTER>, the selected option is activated.
Universal
10.750000 [GHz]
<10.700000 - 11.900000>
Modulation Standard
‚ DVB-S
‚ DVB-S2
ƒ Automatic
