Chapter 3 Front Panel Overview Front Panel Display
© 2012 Harmonic Inc. 33 ProView 7000 v.2.6, Rev. E
The ProView 7100™ and ProView 7000™ front panels comprise the following:
■ Large LCD display – The large LCD display provides enhanced menus with graphical
interface such as charts, radio buttons, tables and icons.
■ Warning and Pwr/Fail indicators – LED status indicators.
■ Arrow keys – Use the four direction arrow keys to navigate the menu items. Use the up and
down arrow keys to select characters for parameters.
■ <ENTER> – Use the <ENTER> key to approve selections and set-ups.
■ <Esc> – Use the <Esc> key to revert selections and set-ups.
■ Function Keys – The <F1> key lists the decoder services and the <F2> key displays the
satellite status report.
■ Alphanumeric keypad (ProView 7100™ only) – Use this keypad to enter digits and
hexadecimal letters. Hold the <Shift> key to enter blue characters. Use the <Clr> key
without <Shift>.
■ Up to four DVB-CI slots – enables you to use up to four Conditional Access Modules (CAMs)
for stream descrambling.
3.2 Front Panel Display
The ProView 7000™ front panel display has four types of pages:
■ Menu
■ Parameter
■ Edit value
■ Radio select
The front panel screen can display up to four items at a time. Additional items can be
accessed using the <up> and <down> arrow keys. To differentiate between the visible and
hidden menu items, two types of screen figures are used in the manual; the dark grey (or
green) displays the first four visible items, an up-and-down icon ( ) and a light grey screen
holding all the additional hidden items.
The following paragraphs describe the various front panel screen page types and how to use
them in menu navigation and managing the device features.
