Operating Specifications12.4
Envelope dimensions and weights
•
Max. length: 13"
•
Max. width: 10"
•
Flap max. height: 3"
-
Min. thickness: 0.008"
-
Max. thickness (manual feed): 0.63"
-
Max. thickness (auto feeding): 0.5"
-
Max. thickness (with sealing): 0.375"
Stack of envelopes
•
Auto feeder: max 4" high
•
Min. weight: 0.1 oz
•
Max. weight: 2 lb.10.23 oz
Label dimensions (pre-cut and self-adhesive)
•
Max. width: 1.57"
•
Min. length: 5.9" (no slogan), 6.5” with slogan or text
•
Max. length: 8.4"
Label storage: recommended room temperature 77°F and relative
humidity 50%. Mind the Best before date.
241
| Page 241 | | feb-14-2014 12:06 |
12
Specifications
