Element DC5X
Veterinary Chemistry Analyzer
Section 10: Specifications
Processing speed 190 tests per hour (simultaneous CM and ISE measurements)
Number of incubator cells CM: 13; ISE: 1
Incubation temperature 98.6°F [37°C] (CM)
86°F [30°C] (ISE)
Incubation time 1 to 6 minutes
Capacity for simultaneously loaded slides 20
Slide lot information Each item: maximum 5 lots
Sampler
1. Number of samples 5 samples (on the sample disk)
2. Sample application fluid volume 50 µl or less (automatic switching)
3. Dilution Automatic dilution (maximum 21x dilution)
Slide ejection Automatic ejection (max. 150 slides into the disposal box)
Used tip ejection Automatic ejection (max. 75 slides into the disposal box)
Measurement wavelengths 400 nm, 415 nm, 505 nm, 540 nm, 577 nm, 600 nm, 625 nm, 650 nm
Light source Halogen lamp (6 V, 10 W)
Measurement precision σ <= 0.0004 OD/5 minutes
Measurement accuracy Within ±0.005 OD (600 nm)
Display 7-inch color touch panel
Backup data of test results For 270 animal patients
Printer Thermal type (paper size: 2.28 in x 82 ft [58 mm x 25 m]
Warming up time Approx. 10 minutes/77°F [25°C], approx. 20 minutes/59°F [15°C]
Environmental conditions Indoor use (6,000 cd/m2 (lux) or lower. 3,000 cd/m2 (lux) or lower when using the
sample barcode reader.)
Altitude: Up to 2,000m (802 hPa)
Transient overvoltage category: II
Pollution degree: 2
Operating temperature: 59 to 89.6°F [15 to 32°C]
Operating humidity: 30 to 80% RH (no vapor condensation)
Storage and transport conditions Temperature: 014 to 122°F [-10 to 50°C]
Humidity: 10 to 90% RH (no vapor condensation)
Voltage used Single phase AC; 100–240 V ±10%; 50 to 60 Hz
Consumption current 3–1.3 A
Type of protection against electrical shock CLASS 1 EQUIPMENT
Volume level Within 70 dB (including buzzer sound)
Data transfer RS−232C (1 port); USB (1 port); LAN (1 port)
External dimensions W 19.7 x D 14.96 x H 16.14 inches [W 500 × D 380 × H 410 mm]
Weight 72.75 lbs [33 kg]
Effective period of service (service life) 6 years after installation
(This period is valid as long as the precautions for use are followed and regular periodic
maintenance is performed correctly.)
10.1 Specifications
