Element DC5X

Veterinary Chemistry Analyzer

Section 2: Part Names, Accessories and Optional Items

2.1 Part Names

Printer

Card reader

LCD (touch panel)

Power button

Disposal box

Sampler cover

Front bottom cover

Sampler cover lock

Incubator cable

Incubator cover

Sampler nozzle cover

Sample disk
