Symbol for separate collection of electric and electronic devices
Symbol accor
ding to directive 2012/19/EU. Applies in the countries
of the European Union, as well as in Norway and Switzerland.
Symbol for potential-free alarm output
This symbol indicates the potential-free alarm output.
Symbol for fuse (for Switchboard option only)
This symbol indicates the fuse 6F1 (for Switchboard option only).
Symbol for analogue output for independent temperature measure-
ment (option)
This symbol indicates the 4-20 mA analogue output for an inde-
pendent temperature measurement.
Symbol for TÜV-inspected device
The device safety requirements are inspected by TÜV (Technischer
Überwachungsverein, Engl: Technical Control Board).
Type plate
Nameplate with technical data specications.
1.2 Symbol on the shipping carton label
This way up.
Shows the correct upright position of the package.
Fragile, handle with care.
Refers to a medical device that can br
eak or be damaged if handled carelessly.
temperature range
The shipping packaging must be stor
ed, transported and handled within the temperature range
shown (-20°C - +60°C).
