Fig. 8: Rear side of device (size 200)
1 For device size 200 only: Thread
insert M6 for xing kit 60012
2 Mains cable connection
3 Potential-free analogue output
4 Standard access port, Ø 42 mm
3.2 Options
Options are articles which are permanently installed
in the device.
3.2.1 Glass door
The glass door consists of several stacked glass panes. The outer
pane of the door is made of safety glass (ESG glass).
Test runs can be inuenced by the allowed incident
light.
For incubators with a glass door, the temperature
deviation values and the power consumption
increase slightly.
Depending on the ambient temperature and the relative ambient
humidity, there may be condensation on the inside and outside of the
glass door. The following diagram illustrates the condensation of the
glass door.
