Fig. 6: Front side of device, door
opened
1 Access port Ø 42 (standard on the
rear side of device)
2 Shelf
3 Interior made of high-quality stain-
less steel 1.4301 (ASTM 304)
4 Shelf, HTS
5 Magnetic seal
6 Door damper
Fig. 7: Access port, rear side
1 Access port
The incubator has a access port with a Ø of 42 mm on the rear side.
Thr
ough this opening, cables from external measuring systems can
be fed into the interior.
After feeding through the cable, the access port
must be sealed with the foam plug included in
delivery to prevent temperature deviations in the inte-
rior. If the access port is not used, this must be
sealed with the screw plug.
