Fig. 57: Main screen, standstill mode,
temperature guard active
1 Temperature guard active display
Fig. 58: Scale, main screen
1 Month
2 Scale, 1 day
3 Temperature process ow
(example)
4
Symbol example
‘Events’
on page 53
The active temperature guard is indicated on the
main scr
een.
6.10 Process ow information
In the process ow information, you can enlarge the process ow in
three different levels.
Level (type number) Scale Displayed time period
Level 0 (main screen)
Entire day One week
Level 1 (type 1x) Entire day 3 days are displayed. One can scroll over
four weeks.
