Technical data
Dimension for option
‘Lateral access
port’
515
±5
387
±5
X
Fig. 218: ‘Lateral access port’ dimension
Æ22 mm Æ42 mm Æ67 mm
X ±5 26 mm 33 mm 40 mm
