Hettich HettCube 200

To Next Page

To Previous Page

23 / 174

12.2020 / Rev. 02

AB66005

Device description

USB port blocker (set) -

For pr

otecting the

USB/A interface. Set

consists of 10 locking

clips and 1 USB key

tool.

60525
