Removing the telescopic rails
Fig. 45: Turning the telescopic rail, front
side
1 Snap-in nose
Fig. 46: Telescopic rail, front side
Fig. 47: Removing the telescopic rail
from the rear latching rail
1. Lift the slide-in module or the drawer, unhook it from the tele-
scope rails and r
emove it.
2. Pull the telescope rails out a little.
3. Hold the telescopic rails at the pulled-out part and slightly twist
towar
ds the centre of the incubator until the snap-in nose proj-
ects from the latching rail.
4. Pull the telescopic rails forward and upward, out of the latching
rail.
5. Pull the telescope rails forward and out from the rear latching
rail and remove.
