Hioki 3196 - Chapter 11 Using the PC

9.2 Using a PC Card
153
When the memory is full
When the memory is full: STOP
Measurement
starts
Measurement forcibly ends
Internal memory
PC card
Internal memory
capacity
Recorded data
Recorded data
PC card capacity
When the memory is full: LOOP
Measurement
starts
Internal memory
PC card
Old data is
deleted
Current time
Measurement stops
Measurement is stopped forcibly
after one month of measurement.
When the PC card memory becomes full,
recording to the PC card stops.
Internal memory
capacity
Recorded data
Recorded data
❖ Settings when the memory is full
(page 83)
