9.2 Using a PC Card
154
Auto-save measured data file (text format) settings
• While auto-save is in progress, do not remove the PC card from the
3196.
• In this case, the only measurement data that can be saved to PC card
in text format is time series data, event list data, flicker data, and volt-
age fluctuation event data.
• Event list data, flicker data, and voltage fluctuation event data
are automatically saved as text, regardless of the TEXT save
options.
• Settings selected in the text save options also apply when manually
saving text data.
❖ Manual saving of the measured data files 2 (Text format: time-
series/ event list/ flicker data) (page 150)
RECORDING
Interval
Files are saved automatically when the internal operation status be
comes [RECORDING].
Measured data files are saved automatically during recording.
Auto Save
Measured data files are saved to the PC card with the internal
memory automatically.
SELECT
Select the item to be saved.
The item currently selected appears to the right of the auto-save se
tings.
OFF: Not selected as an item to be saved as text.
ON: Selected as an item to be saved as text.
Select from pull-
down menu
1. Set the interval. (page 84)
1, 3, 15, or 30 sec, 1, 5, 10, 15, or 30 min, 1/2 hour
2. Set the auto-save format.
TEXT
Select the item
to be saved.
OFF
ON
RETURN
To Next Page
