Replacing (ejecting) media during real-time save operation
This section describes how to replace media while real-time saving is enabled.
It also describes how to check data on media during extended recording.
1
2
1
Press the ENTER key while [Eject] on the top right of the waveform screen is selected.
The media exchange window will be displayed.
2
Select the media you wish to eject and press the ENTER key while [OK] is selected.
SD card

, USB ash drive
3
Once either [USB ash drive can be safely removed] or [SD card can be safely removed] has
been displayed on the screen, eject the media.
• Waveform data while the media was ejected is written to the instrument’s internal bu󰀨er memory.
• When both an SD Memory Card and a USB Drive are inserted, ejecting the media containing
data will switch the save destination over to the other media.
4
Insert formatted media.
When you insert media into the instrument, the instrument will save data that has been written to
the internal bu󰀨er memory to the media, and then resume recording waveform data.
IMPORTANT
• If you do not nish the replacement of media within two minutes after pressing the
ENTER key with [Eject] selected, the internal bu󰀨er memory could run out, resulting in
data missing.
• When the media is replaced while real-time save operation is in progress, subsequent
data will be saved in a di󰀨erent le.
• If measurement stops while the media is ejected, the data until the point at which
measurement stopped will not be saved, even if new media is inserted after
measurement stopped.
• If [FTP data auto send] is on, les that have not sent at the time when the ENTER key
is pressed with [Eject] selected will not be sent.
