Hioki MEMORY HiLOGGER LR8450 User Manual

223
8
External Control (EXT. I/O)
This chapter describes how to control the instrument by
inputting signals to its external control terminals.
Signals corresponding to the instrument’s operation are
output from the external control terminals.
You can congure settings related to the external control
terminals on the [System] > [External] settings screen.
The external control terminals are not isolated (they use the
same ground as the instrument).
For more information about how to connect signals to the
external control terminals, see “External Control Connections”
in the Quick Start Manual.
8.1 Conguring Voltage Output (VOUTPUT) ............................p. 224
8.2 Conguring Alarm Output (ALARM) ...................................p. 225
8.3 Conguring External Input/Output (I/O) Terminals ...........p. 227
External trigger input ..............................................................................p. 229
Trigger output .........................................................................................p. 230
Simultaneously starting measurement using external triggers ............... p. 232
8 External Control (EXT. I/O)
External Control (EXT. I/O)
