Hioki MEMORY HiLOGGER LR8450 User Manual

238
Conguring and Establishing a USB Connection
Connecting the instrument to the computer with a USB cable
This section describes how to connect the instrument to a computer with a USB cable.
NOTICE

Do not unplug the USB cable while the instrument is sending or receiving data.
Doing so could damage the instrument.

Turn o󰀨 the instrument and computer before connecting or disconnecting the
USB cable.
Failure to do so could cause the instrument to malfunction or damage it.

Ensure the instrument and computer are grounded at the same potential.
Connecting the USB cable while the ground potentials di󰀨er between the instrument
and computer could cause the instrument to malfunction or damage it.
Instructions
1
Insert the USB cable plug into the
instrument’s USB cable connector,
exercising care to ensure that the plug is
oriented properly.
2
Connect the other end of the USB cable
to the computer’s USB connector.
You cannot use both the Logger Utility and communication commands at the same time over
the USB connection. Allow at least 30 s to switch between the Logger Utility and communication
commands.
HIOKI LR8450A964-03
www.GlobalTestSupply.com
Find Quality Products Online at: sales@GlobalTestSupply.com

Hioki MEMORY HiLOGGER LR8450 Specifications

General

Storage Media	SD card (up to 32 GB)
Measurement Types	Voltage, Temperature, Resistance, Strain, Pulse, Logic
Sampling Rate	1 ms to 1 hour
Interface	LAN, USB, SD card slot
Power Supply	100 to 240 V AC, 12 V DC
Resolution	16-bit
Voltage Range	±10 mV
