Hioki MEMORY HiLOGGER LR8450 User Manual

158
Loading Data
5
Select the le loading mode on the conrmation window, and press the ENTER key while [OK]
is selected.
OVERWRITE
mode
Saves the loaded data by overwriting the
existing setting conditions.
The instrument’s present settings will change.
The status bar will remain gray.
VIEW mode Loads the data to browse.
The instrument’s present settings will not
change.
The status bar will turn green.
6
On the conrmation window, select the check boxes for the loading settings.
You can load the wireless module registration information (LR8450-01 only), system congurations
(environments, external terminal), and communications settings (LAN, USB).
When the [VIEW mode] is selected, the instrument will load the wireless module registration
information. (The check box cannot be selected.)
When loading waveform data, information about the saved waveform data will be displayed.
7
7
6
6
Loading waveform data
The conrmation window will include information such as the trigger time and the channel number
the data of which is saved.
If the le being loaded is larger than the capacity of the internal bu󰀨er memory, specify the start
point of the waveform data to load. The system will load the data containing the number of data
points specied in [Readable data num] starting at the specied point.
7
Press the ENTER key while [OK] is selected.
The data will be loaded.
HIOKI LR8450A964-03
www.GlobalTestSupply.com
Find Quality Products Online at: sales@GlobalTestSupply.com

Hioki MEMORY HiLOGGER LR8450 Specifications

General

Storage Media	SD card (up to 32 GB)
Measurement Types	Voltage, Temperature, Resistance, Strain, Pulse, Logic
Sampling Rate	1 ms to 1 hour
Interface	LAN, USB, SD card slot
Power Supply	100 to 240 V AC, 12 V DC
Resolution	16-bit
Voltage Range	±10 mV
