Hioki MEMORY HiLOGGER LR8450 User Manual

255
Performing Remote Operation Using the HTTP Server
4
Select the mode.
Control Mode Allows you to control and congure the instrument from a browser.
Only one connection is supported.
Browsing Mode You can view the instrument’s screen and information about its status from a
browser.
Up to four simultaneous connections are supported.
If nothing appears on the HTTP screen
Perform the following steps.
1
Under the Internet Explorer
®
settings, click [Tools] > [Internet options].
2
Enable [Use HTTP1.1] on the [Advanced] tab and disable [Use HTTP1.1 through proxy
connections].
3
Under [LAN settings] on the [Connections] tab, disable the [Proxy server] setting.
Check whether you can communicate with the instrument over the LAN connection.
See “Troubleshooting LAN connections” (p. 249).
Communicating with a Computer (PC)
HIOKI LR8450A964-03
www.GlobalTestSupply.com
Find Quality Products Online at: sales@GlobalTestSupply.com

Hioki MEMORY HiLOGGER LR8450 Specifications

General

Storage Media	SD card (up to 32 GB)
Measurement Types	Voltage, Temperature, Resistance, Strain, Pulse, Logic
Sampling Rate	1 ms to 1 hour
Interface	LAN, USB, SD card slot
Power Supply	100 to 240 V AC, 12 V DC
Resolution	16-bit
Voltage Range	±10 mV
