309

9. Input
Pulse/logic input Number of channels 8 channels (common GND, non-isolated)
Exclusive setting for pulse/logic input for individual channels
Terminal block Push-button type terminal block
Adaptive input format Non-voltage contact, open collector (PNP open collector
requires external resistor), or voltage input
Maximum input voltage 0 V to 42 V DC
Input resistance 1.1 M

Detection level 2 levels (user-selectable)
High: 1.0 V or greater; low: 0 to 0.5 V
High: 4.0 V or greater; low: 0 to 1.5 V
Pulse input Measurement range, resolution
Measurement
target
Range
Maximum
resolution
Measurable range
Integration 1000 M pulse f.s. 1 pulse 0 to 1000 M pulse
Rotational
speed
5000/n (r/s) f.s. 1/n (r/s) 0 to 5000/n (r/s)
300,000/n (r/min.) f.s. 1/n (r/min.) 0 to 300,000/n (r/min.)
n: Number of pulses per rotation (1 to 1000)
Pulse input period 󰀨

interval)

100 ms or greater (50 ms or greater during high and low
interval)
Slope Set rising/falling for each channel.
Measurement mode Integration (addition, instantaneous), rotational speed
Integration Addition: Counts the number of pulses input from start of
measurement.
Instantaneous: Counts the number of pulses input within each
recording interval (integrated value is reset for
each rotational interval).
Rotational speed r/s: Counts the number of input pulses during 1 s and
calculates the rotational speed.
r/min.: Counts the number of input pulses during 1 min. and
calculates the rotational speed.
Smoothing function Select value from 1 s to 60 s (valid only when set to rotational
speed and r/min.).
 󰀨
Logic input Measurement mode Records 1 or 0 for each recording interval.
10. Accessories and options
Accessories See “Accessories” in the Quick Start Manual.
Options See “Options (sold separately)” in the Quick Start Manual.

