321
Measurement
target
Type Range
Maximum
resolution
Measurable range
Measurement
accuracy
Humidity –
f.s.
As per measurement
accuracy of the Z2000
Humidity Sensor
5030200
0
5
60
80
95
100
±8% RH
±6% RH
±5% RH
±10% RH
±8% RH
±6% RH
±10% RH
±8% RH
±6% RH
Temperature (°C)
Humidity accuracy table
: Out of accuracy guarantee range
Each boundary line is included in the better measurement accuracy area.
Resistance
temperature
detector
Pt100 100°C f.s. 0.01°C ±0.5°C
500°C f.s. 0.05°C ±0.7°C
2000°C f.s. 0.1°C
JPt100 100°C f.s. 0.01°C ±0.5°C
500°C f.s. 0.05°C ±0.7°C
2000°C f.s. 0.1°C
Pt1000 100°C f.s. 0.01°C ±0.5°C
500°C f.s. 0.05°C ±0.7°C
2000°C f.s. 0.1°C
Resistance – 10
f.s. 0.5 m
0
to 10
±10 m
20
f.s. 1 m
0
to 20
±20 m
100
f.s. 5 m
0
to 100
±100 m
200
f.s. 10 m
0
to 200
±200 m
Accuracy of
reference junction
compensation
±0.5°C (with input terminal temperature balancing)
Reference junction compensation:
Add thermocouple measurement accuracy when set
to internal.
Temperature
characteristics
humidity, see humidity accuracy table).
Normal-mode
rejection ratio
50 dB or greater
interval of 5 s)
interval of 5 s)
(With thermocouple wire break detection disabled)
Common-mode
rejection ratio
Signal source resistance of 100
or less
100 dB or greater
(With 50 Hz/60 Hz input and a data refresh interval of 10 ms)
140 dB or greater
interval of 5 s in the 10 mV f.s. range)
interval of 5 s in the 10 mV f.s. range)
(With thermocouple wire break detection disabled)
