339
Accessories Z3230 Wireless LAN Adapter
Instruction Manual
Mounting plate
M3×4 screws ×2 (for the mounting plate)
Options Z3230 Wireless LAN Adapter
Z1007 Battery Pack
C1012 Carrying Case
2. Input, output, and measurement specications
-1. Basic specications
Number of input
channels
15 channels (Set voltage or thermocouple for each channel.)
Input terminals
Measurement target Voltage
Input type
All channels isolated
A/D resolution 16 bits
Maximum input
voltage
±100 V DC
Maximum channel-to-
channel voltage
300 V DC
Maximum rated
terminal-to-ground
voltage
300 V AC, DC (Measurement Category II)
Anticipated transient overvoltage: 2500 V
Input resistance 10 M
or greater (10 mV f.s. to 2 V f.s. voltage ranges, all thermocouple ranges)
1 M
Allowable signal
source resistance
1 k
or less
Reference junction
compensation
Internal/external (user-selectable) (during thermocouple measurement)
Thermocouple wire
break detection
The system will check for wire breaks at the date refresh intervals during thermocouple
measurement.
(Setting not available when the data refresh interval is set to 10 ms.)
Data refresh interval 10 ms*, 20 ms, 50 ms, 100 ms, 200 ms, 500 ms, 1 s, 2 s, 5 s, 10 s
*: Setting available when thermocouple wire break detection is disabled.
