Settings after Initialization (System Reset)
Screen Setting
Main Sub Setting Default setting
Measure CAN Unit Operating mode Receive mode
Title –
Port settings Interface CAN FD
Terminator
(OFF)
ACK
(OFF)
CAN/
CAN FD (arbitration)
Baud rate 500 kBaud
Sampling point 80.0%
CAN FD (data) Baud rate 2.0 MBaud
Sampling point 80.0%
User frame transmission
(OFF)
Channel Individual Channel Measurement
(ON)
Input Input type Voltage
Range 10 mV
Display Position
Zoom ×1
Zero position 50%
Scaling OFF
Comment –
Numerical threshold 0
UNIT (CAN) Measure OFF
Trigger Common Trigger OFF
Timing Start
Pre-trigger Time 0 Days 00:00:00
Condition Start OR
External trigger OFF
Interval trigger OFF
Unit n
(n = 1, 2, . .)
Type Start OFF
Stop OFF
CAN Register OFF
Alarm Common Alarm OFF
Alarm hold OFF
Alarm buzzer OFF
Event mark OFF
Alarm history Start 100
Alarm 1-8 ALM1 to ALM8 Filter OFF
Comment –
Unit ALM OFF
CAN Register OFF
