Hioki RM2610 - Page 100

96
How is interface resistance calculated?
1
Modeling
Interface
Collector
Composite layer
R1
R2
R3
2
Potential
measurement
V
d
Composite
layer
Interface
Electrode sheet
Collector
Surface potential
distribution
(representative)
Update
resistance
value
Don’t
agree
3
Calculation of
potential using a
simulation
Virtual electrode
sheet
Surface potential
distribution
(representative) as
calculated by simulation
R1
R2
R3
V
d
4
Comparison
of observed potential
and calculated
potential
V
d
Surface potential
distribution
(representative)
V
d
Surface potential
distribution
(representative) as
calculated by simulation
Agree
5
Output (end)
