Part Names and Functions
RM9003 Press Unit
CAUTION
To avoid equipment damage, turn off the RM2611 Electrode Resistance Meter before
connecting or disconnecting the RM9005 Connection Cable.
IMPORTANT
• When connecting the RM9005 Connection Cable, insert the cable into the connector rmly and tighten it in
place with screws. If the screws loosen, the resulting poor contact could cause a measurement error.
• The device ships with the up/down lever locked with the lock release lever clamp knob. Loosen the knob
before using the device for the rst time.
1
2
3
4
5
6
15
7
14
9
10
12
(Front)
(Rear)
8
11
13
11
(Rear)
13
To Next Page
