Output File Formats
7.3 Output File Formats
Analysis results le format
Header Description
Counter Counter [measurements]
Date Measurement start date
Time Measurement start time
Comment Comment (up to 30 characters)
Composite volume resistivity [ohm cm] Composite layer volume resistivity [
Ω
cm]
Interface resistance [ohm cm^2] Interface resistance [
Ω
cm
2
]
Composite surface resistivity [ohm cm^2] Composite layer surface resistivity [
Ω
cm
2
]
Range [ohm] Resistance range
Speed Potential measurement speed
TF-Type Fixed value of 1
Composite layer thickness [um] Composite layer thickness [μm]
Collector layer thickness [um] Collector thickness [μm]
Collector resistivity [ohm cm] Collector volume resistivity [
Ω
cm]
Model area Model area {NORMAL | MEDIUM | WIDE}
Element size Element size {NORMAL | FINE | SUPER FINE}
Limit iteration number Limit iteration number [iterations]
Reduction factor Reduction factor
Initial composite resistivity [ohm cm] Composite layer volume resistivity initial value setting [
Ω
cm]
Initial Interface resistance [ohm cm^2] Interface resistance initial value setting [
Ω
cm
2
]
Contact check-V Contact check results (32-bit hexadecimal value) (p. 87)
Contact check-I Contact check results (32-bit hexadecimal value) (p. 87)
Potential consistency Potential distribution consistency
Variation-V Potential variability [%]
Error data Number of error data rejections [rejections]
Measurement Time [s] Potential measurement time [s]
Temperature [deg C] Temperature [°C]
Calculation Analysis results {PASS | FAIL}
Iteration number Iteration number [iterations]
Coincidence Coincidence
Calculation Time [s] Analysis time [s]
RM2611 SN RM2611 Electrode Resistance Meter serial number
RM2611 Version RM2611 Electrode Resistance Meter rmware version
RM2612 Version PC application version
RM2612 Analysis version Analysis unit version
