Hioki RM2610 - RM2611 Electrode Resistance Meter

10
Part Names and Functions
RM2611 Electrode Resistance Meter
CAUTION
Do not connect anything to the maintenance ports (labeled “6” and “7” in the gure
below). Connecting a cable to the maintenance ports could cause instrument
malfunction or damage.
1
2
Keys
(Front)
(Rear)
(Rear)
(Front)
2
5
8
9
4
3
11
10
(Do not use.)
6
7
(Do not use.)
(Do not use.)
