Disposing of the RM2611 Electrode Resistance Meter
Necessary tools: Philips screwdriver (No. 1 size) and pair of tweezers (for removing the
lithium battery)
1
Verify that the RM2611 Electrode
Resistance Meter’s main power switch (on
the rear of the instrument) is in the OFF (○)
position and disconnect all cords.
2
Remove the six screws from the sides and
one screw from the rear.
(As seen from above)
(Front)
(Rear)
Connector
3
Remove the cover.
4
Remove the four screws and lift up the
MUX unit frame. (Do not disconnect the
connector that connects the MUX unit
frame to the RM2611 Electrode Resistance
Meter.)
Battery holder
(As seen from above)
5
Insert the tweezers into the space between
the battery and the battery holder and
remove the battery while lifting up on it,
as shown in the gure.
CALIFORNIA, USA ONLY
Perchlorate Material - special handling may apply.
See www.dtsc.ca.gov/hazardouswaste/perchlorate
To Next Page
