MAINTENANCE AND ADJUSTMENT OF THE UTV
- 88-
5. Adjust:
valve clearance
① Lock nut
② Valve thickness gauge（gap Regulation）
③ Regulator
④ Adjust tools
· Loosen the locknut .①
· Insert a thickness gauge between the③
adjuster end and the valve end.
· Turn the adjuster clockwise or ③
counterclockwise with the tappet adjusting
tool until the proper clearance is obtained.④
· In order to avoid the regulator, adjust
rotation together after fastening tool fixed
lock nut.
·
Measuring clearance rules with the valve
clearance.
·If the gap beyond the standard value, repeat
the above steps until the correct gap.
6. Install all removed parts
According to remove the reverse order for
installation
·Engine fan components
·Fan cover
·spark plug
·Valve cover (exhaust)
·Valve cover (intake)
·Lower the cargo bed.
·console
·passenger seat
·driver seat
Refer to “SEATS,” in chapter 5.
14Nm（1.4kg.m）
