CHASSIS
- 255-
INSTALLING THE FRONT BRIDGE PARTS
1. Put the left and right transmission shaft in the
front bridge differential device.
2. Pour 0.32L SAE 80 API GL-4 the high
quality gear grease into the front bridge
differential device and screws tight the oil
filler bolt.
Fastening Torque of Conical Nut
23 Nm (2.3m · kg,17 ft · lb)
3. Install the front bridge differential device onto
the frame with two pieces of hexagon bolts
M10×110,two pieces of nuts M10 and two
pieces of flat gasket.
Fastening Torque
of the Bolt
40～45 Nm 4.0～4.5 m · kg,29～33 ft · lb)
