CHASSIS

- 268-

No. Part Name Qty Remarks

13 Clip Φ14 1

14 Draining tube 1

Adjust nut M8（L)

16 Gear shifting support 1

17 Hexagon flange bolt M6×12 2

18 Reverse cable 1

19 Spring washer -6 1

20 Plug 1

21 Hexagon flange nut M8 2
