ELECTRICAL COMPONENTS
- 336 -
Procedure
Check:
1. Fuses (main, four-wheel drive)
2. Battery
3. Main switch
4. Four-wheel drive relay 1
5. Four-wheel drive relay 2
6. Four-wheel drive relay 3
1. Fuses (main, four-wheel drive)
Refer to “CHECKING THE SWITCH”.
CONTINUITY
2. Battery
• Check the battery condition. Refer to
“CHECKING AND CHARGING THE BATTERY”
in chapter 3.
Open-circuit voltage:
12.8 V or more at 20 °C (68 °F)
CORRECT
3. Main switch
Refer to “CHECKING THE SWITCH”.
CORRECT
7. On-Command four-wheel drive switch and
differential gear lock switch
8. Gear motor
9. Wiring connections
(the entire 2WD/4WD selecting system)
1NOTE:
• Remove the following part(s) before
troubleshooting.
1. Console
• Use the following special tool(s) fo
r
troubleshooting.
NO CONTINUITY
Replace the fuse
INCORRECT
• Clean the battery terminals.
•Recharge or replace the battery
INCORRECT
Replace the main switch.
TROUBLESHOOTING
IF THE FOUR-WHEEL DRIVE INDICATOR FAILS TO COME ON:
