Figure Legend
1. Scroll between the two screens using the arrows.
2. Use the on-screen keyboard to type, edit, and remove Filter Comments.
3. The Procedure Info is the information already in the system for the procedure. It cannot be
edited on the Filter Info and Comments screen.
4. Select the Save button to save the Filter Info and Comments.
5. Indicate the quadrant for the specimens in that particular tissue filter.
6. Select the Back button to exit the Filter Info and Comments screen without saving and return to
the previous screen. If there are unsaved changes, a prompt displays the option to save or
continue without saving the comments.
7. Enter, edit, and remove additional Filter Comments using the on-screen keyboard.
8. Select from a predefined list describing the specimens in that particular tissue filter.
9. Use these circles to scroll between the two screens. A red exclamation point in a circle
indicates that there is an error that needs to be fixed on that screen.
8.2.5 How to Reimage
Select the Reimage button to acquire a new image of the core shown in the active image.
8.3 Send the Images to the Output Devices
You can send the images to output devices or use the Export function to copy images to a
temporary storage device. Refer to How to Use the Output Set on page 53 for instructions.
