Brevera Breast Biopsy System User Guide
Chapter 3: Components, Controls, and Indicators
MAN-04303-002 Revision 006 Page 31
3.2 System Connections
This section provides information on how to make all of the necessary connections to set
up the Brevera breast biopsy system for use. The following connections will be explained:
1. Power and network connections
2. Footswitch connection
3. Device driver and remote control connection
4. Suction canister connections
5. Biopsy needle (needle, tubing, and tissue filter) connections
Figure 12: System Connections
