Brevera Breast Biopsy System User Guide
Chapter 4: User Interface - Imaging Display
MAN-04303-002 Revision 006 Page 51
Shows the patient name and ID.
Real-time image of the specimen in the tissue filter. The letter-designation on the
tissue filter chamber is visible in the image.
Shows the status of the console, needle, and imaging functions.
A green name in the imaging status area of the taskbar indicates that function is
in a ready status. A gray name in the imaging status area indicates that function
is not ready. A yellow/orange in the imaging status indicates that an x-
ray is being taken. Refer to About the Taskbar on page 43 for more information on
the taskbar.
Use the image enhancement tools (refer to Image Enhancement Tools on page 92) to
enhance the whole image or areas of interest in the image.
Selects a particular image or images. Tagged images show a green check mark in
a circle in the upper right corner of the image as well as the image thumbnail.
View the list of procedures for the current patient. Use the + button to add a
procedure for the current patient.
Review and annotate images, reimage specimens already in the tissue filter
chambers, select the output destination for acquired images, or close the patient.
Shows small icons of images related to the selected tissue filter. A thumbnail
image with a camera icon is a snapshot image.
Use the Filter bar at the top of the image thumbnails ("Filter: 1/1" shown) to
navigate through multiple tissue filters.
