Brevera Breast Biopsy System User Guide
Chapter 4: User Interface - Imaging Display
MAN-04303-002 Revision 006 Page 57
7.
Image thumbnails
Choose the images to output by touching the image
thumbnail. The selected image thumbnail is
surrounded by a green box in the thumbnail area and
the position of that image appears as a green box in
the film format area.
8.
Auto All
Automatically select all of the images for that
procedure to be printed.
9.
Auto Tagged
Automatically select the images that are tagged on the
Procedure screen for that procedure to be printed, and
automatically create a film or films for them.
10.
Reset
Return the Print screen to its previous settings and
remove any images from a film or films.
11.
Properties
Open the Properties screen for selection of the printer
defaults.
12.
Printer Info
Show the printer IP address, AE Title, Port and
capability for True Size print.
13.
Print
Output the current films to the print preview area and
start the printing process. To allow for subsequent
printing and printing to another device, the images
remain in the print preview until the user removes
them.
14.
Back
Cancel the print job and return to the Procedure screen.
If print jobs have been created but not yet printed, the
system will ask the user to confirm the cancelation.
1. On the Procedure screen, select the Print button. The Print screen appears.
2. Select the film format from the Options area of the screen.
3. Select an image thumbnail on the right side of the screen.
4. Select the Print preview on the left side of the screen to put the selected image on the
film.
5. To put other images on the film, repeat steps 3 and 4.
6. To print a different film format of the same images, select the New Film button and
repeat steps 2 to 4.
7. Select the Print button to print your films.
