Introduction - Model Selection Guide
Revision 19 HC900 Process Controller Installation and User Guide 3
06/14
Description Model number
I/O Components
Low VoltageTerminal Block (Euro style) 900TEK - 0001
Low VoltageTerminal Block (Barrier Style) 900TBK -0001
High VoltageTerminal Block (Euro style) 900TER - 0001
High Voltage Terminal Block (Barrier Style) 900TBR - 0001
High Density Terminal Block 900TCK - 0001
Analog Input Remote Terminal Panel (RTP) 900RTA - L001
I/O Components
Relay Output Remote Terminal Panel (RTP) 900RTR - H001
DI, DO, AO Remote Terminal Panel (RTP) 900RTS - 0001
Low Voltage RTP Cable (1.0M, 3.28ft.) 900RTC - L010
Low Voltage RTP Cable (2.5M, 8.2ft.) 900RTC - L025
Low Voltage RTP Cable (5.0M, 16.4ft.) 900RTC - L050
High Voltage RTP Cable (1.0M, 3.28ft.) 900RTC - H010
High Voltage RTP Cable (2.5M, 8.2ft.) 900RTC - H025
High Voltage RTP Cable (5.0M, 16.4ft.) 900RTC - H050
High Density RTP Cable (1.0M, 3.28ft.) 900RTC - 3210
High Density RTP Cable (2.5M, 8.2ft.) 900RTC - 3225
Filler Block Terminal Cover 900TNF - 0001
Shield Terminal Strip (package of 2) 900TSS - 0001
Terminal board jumpers (10, two pos jumpers) 900J02 - 0001
Terminal board jumpers (10, ten pos.jumpers) 900J10 - 0001
Manuals
Full Document set on CD 900ME1-00XX-XX
Full document set, hard copy - English 900ME2-00XX-XX
Software
HC Designer Config. Software CD 900W01-00XX-XX
HC Utilities Software/Documentation CD 900W02-00XX-XX
Kits & Accessories
Redundant Power, Rack Extension Kit 900RPE-0001
Spare I/O Label Kit 51452262-501
Replacement Battery Kit 51500638-501
Ethernet Cable (10 feet) 51451432-010
Ethernet Cable (20 feet) 51451432-020
Ethernet Cross-over Cable (20 feet) 51451996-020
Null Modem Cable 51404755-501
Null Modem Cable used with 900C70R 50004820-501
250 ohm Shunt Resistor Kit ( (8/pkg.) 51205995-501
Ethernet Switching Hub (8 Ports) 50008930-001
24 VDC Power Supply 51452041-501

Honeywell HC900 Specifications

General

Series	HC900
Redundancy	Optional
Programming Language	Function Block Diagram, Ladder Logic, Structured Text
Inputs	Analog, Digital
Outputs	Analog, Digital, Relay
Display	Optional
Control	PID, Advanced Control
Power Supply	24V DC or 100-240V AC
Storage Temperature	-40°C to 85°C
Humidity	5% to 95% non-condensing
Communication Protocols	Modbus, Ethernet
