Honeywell HC900 User Manual

Introduction - Model Selection Guide
2 HC900 Process Controller Installation and User Guide Revision 19
06/14
Model Selection Guide
Legacy System
Description Model number
Racks
4 I/O Slot Rack 900R04 – 0001
8 I/O Slot Rack 900R08 – 0101
12 I/O Slot Rack 900R12 - 0101
8 Slot Rack -Red. Power 900R08R - 0101
12 Slot Rack - Red. Power 900R12R - 0101
Redundant CPU Rack 900RR0 - 0001
Controllers
Controller C50 CPU Config.SW & Docs 900C51 – 00XX-00
Controller C50 CPU 900C52 – 00XX-00
Controller C30 CPU Config. SW & Docs 900C31 – 00XX-00
Controller C30 CPU 900C32 – 00XX-00
Controller C70 CPU Config.SW & Docs 900C71-00XX-00
Controller C70 CPU 900C72-00XX-00
Controller C70R CPU Config.SW & Docs 900C71R-0000-XX
Controller C70R CPU 900C72R-0000-XX
Redundancy switch module 900RSM - 0001
I/O Scanner - 2 Port (1 per I/O rack) 900C73R-0000-XX
I/O Scanner (for remote rack) 900C53 – 00XX-00
Redundant Power Status Module 900PSM - 0001
Power Supplies
120/240VAC, 60W 900P01 -0001
120/240VAC, 28W 900P02 -0001
+24VDC 900P24-0001
I/O Modules
Analog Input (8 channel) 900A01 - 0102
High Level Analog Input (16 channel) 900A16 - 0001
Analog Output, 0 to 20mA, (4 channel) 900B01 -0101
Analog Output, 0 to 20mA, (8 channel) 900B08 – 0001
Analog Output, 0 to 20mA, (16 channel) 900B16 - 0001
Digital Input, Contact type, (16 channel) 900G01 - 0102
Digital Input, 24VDC (16 channel) 900G02 - 0102
Digital Input, 24VDC (32 channel) 900G32 - 0001
Digital Input, 120/240 VAC, (16 channel) 900G03 - 0102
Digital Input, 120/240VAC, 125VDC (16ch-Iso) 900G04 - 0001
Digital Output, Relays ( 8 channel) 900H01 - 0102
Digital Output, 24VDC (16 channel) 900H02 - 0102
Digital Output, 24VDC (32 channel) 900H32 - 0001
Digital Output, 120/240 VAC (8 channel) 900H03 - 0102
Pulse/Frequency/Quadrature 900K01 - 0001

Honeywell HC900 Specifications

General

Series	HC900
Redundancy	Optional
Programming Language	Function Block Diagram, Ladder Logic, Structured Text
Inputs	Analog, Digital
Outputs	Analog, Digital, Relay
Display	Optional
Control	PID, Advanced Control
Power Supply	24V DC or 100-240V AC
Storage Temperature	-40°C to 85°C
Humidity	5% to 95% non-condensing
Communication Protocols	Modbus, Ethernet
