Specifications - System Sizing and Availability Summary
Revision 19 HC900 Process Controller Installation and User Guide 203
06/14
System Sizing and Availability Summary
Table 42 – System Size and Availability Summary
Specification C30 C50 C70 C75
Combined Analog and Digital I/O 384 points 1920 points 1920 points 1920 points
Analog Inputs 142 points 960 points 960 points 960 points
Analog Outputs 40 points 200 points 200 points 200 points
Block inputs Quantity based on available memory
Block parameters Quantity based on available memory
Block values 375,000 375,000 375,000 375,000
FDB worksheets 20 20 40 40
Function blocks 400 2000 5000 5000
Local I/O Yes Yes Yes No
Loop blocks Quantity based on available memory
Modbus registers used by slave blocks 1024 1024 1024 1024
Modbus slave blocks 32 32 32 32
Numeric constants Quantity based on available memory
Page connectors 200 1000 2500 2500
Peer blocks 32 32 32 32
Peer data exchange items 2240 2240 2240 2240
Position proportional output blocks Quantity based on available memory
Profiles in Pool User Configurable
Ramp blocks Quantity based on available memory
Recipes in Pool User Configurable
Redundancy capability No No No Yes
Redundant host comms. No No Yes Yes
Schedules in Pool User Configurable
Segments per profile 50 50 50 50
Sequencer blocks Quantity based on available memory
Sequences in Pool User Configurable
Setpoint programmer blocks Quantity based on available memory
Setpoint scheduler blocks Quantity based on available memory
Signal tags Quantity based on available memory
Soft Wire bytes Quantity based on available memory
Stage blocks Quantity based on available memory
Steps per schedule 50 50 50 50
Steps per sequence 64 64 64 64
Support of dual port scanner No No No Yes
Tag descriptor Quantity based on available memory
Text bytes Quantity based on available memory
Variables 2000 2000 2000 2000
Variables in a Recipe 50 50 50 50
