Specifications - HC900 Analog Input Ranges vs. UMC800 Analog Input ranges
200 HC900 Process Controller Installation and User Guide Revision 19
06/14
HC900 Analog Input Ranges vs. UMC800 Analog Input ranges
Users of UMC800 Controllers from Honeywell will find the analog range selections of the HC900
Controller differ slightly from those available in the UMC800. These differences are indicated in Table 41
in the column identified “(Reference): Corresponding UMC800 Input type and range”. The number to the
right of the range data indicates the range number reference for the UMC800 range table.
When using the Designer Software configuration software to convert UMC800 configuration files to
HC900 configuration files, the HC900 range to the left of the UMC800 data will be used by the conversion
program. There may also be UMC800 ranges that are not supported by the HC900 Controller. For these
ranges the conversion process will default the range data to a null, not-programmed, range.
Table 41 - HC900 PV Input Types and Ranges
Type Range
Low
Range High EU (Reference): Corresponding
UMC800 Input type and range
None n/a
B -18 1815 C B 40 1820 C 58
B 0 3300 F B 104 3308 F 59
E -270 1000 C n/a
E -454 1832 F n/a
E -129 593 C n/a
E -200 1100 F n/a
J -18 871 C J –200 870 C 4
J -7 410 C J 0 400 C 2
J 20 770 F J 32 752 F 3
K -18 1316 C K 0 1200 C 16
K 0 2400 F K 32 2192 F 17
K -18 982 C K 0 800 C 14
K 0 1800 F K 32 1472 F 15
K -29 538 C K 0 400 C 12
K 20 1000 F K 32 752 F 13
Ni-NiMo 0 1371 C NiMo 0 1400 C 50
Ni-NiMo 32 2500 F NiMo 32 2552 F 51
Ni-NiMo 0 682 C n/a
Ni-NiMo 32 1260 F n/a
NiMo-NiCo 32 2500 F MoCo 32 2552 F 111
NiMo-NiCo 0 682 C n/a
NiMo-NiCo 32 1260 F n/a
NiCroSil-NiSil -18 1300 C N 0 1200 C 24
NiCroSil-NiSil 0 2372 F N 32 2192 F 25
NiCroSil-NiSil -18 800 C N 0 800 C 22
NiCroSil-NiSil 0 1472 F N 32 1472 F 23
R -18 1704 C R -20 1760 C 28
R 0 3100 F R -4 3200 F 29
S -18 1704 C S 0 1600 C 30
