Specifications - HC900 Analog Input Ranges vs. UMC800 Analog Input ranges
Revision 19 HC900 Process Controller Installation and User Guide 201
06/14
Type Range
Low
Range High EU (Reference): Corresponding
UMC800 Input type and range
S 0 3100 F S 32 2912 F 31
T -184 371 C T –200 400 C 40
T -300 700 F T –328 752 F 41
T -129 260 C T -50 150 C 34
T -200 500 F T -58 302 F 35
W_W26 -20 2320 C W_W26 -20 2320 C 52
W_W26 -4 4200 F W_W26 -4 4208 F 53
W5W26 -18 2316 C W5W26 -20 2320 C 54
W5W26 0 4200 F W5W26 -4 4208 F 55
W5W26 -18 1227 C n/a
W5W26 0 2240 F n/a
Platinel 0 1380 C PLTNL 0 1380 C 118
Platinel 32 2516 F PLTNL 32 2516 F 119
Platinel 0 750 C PLTNL -70 750 C 116
Platinel 32 1382 F PLTNL -94 1382 F 117
Pt100 -184 816 C Pt100 –200 800 C 68
Pt100 -300 1500 F Pt100 –328 1472 F 69
Pt100 -184 649 C n/a
Pt100 -300 1200 F n/a
Pt100 -184 316 C Pt100 -50 150 C 60
Pt100 -300 600 F Pt100 -58 302 F 61
Pt500 -184 649 C n/a
Pt500 -300 1200 F n/a
Pt1000 -40 260 C Pt1000 –50 400 C 120
Pt1000 -40 500 F Pt1000 –50 752 F 121
JIS100 -200 500 C JIS -200 500 C 78
JIS100 -328 932 F JIS -328 932 F 79
JIS100 -200 260 C JIS 0 100 C 72
JIS100 -328 500 F JIS 32 212 F 73
Cu10 -20 250 C Cu10 -20 250 C 84
Cu10 -4 482 F Cu10 -4 482 F 85
YSI405 10 37.8 n/a
YSI405 50 100 n/a
Ohms 0 200 Ohms 0 200 86
Ohms 0 500 n/a
Ohms 0 1000 n/a
Ohms 0 2000 Ohms 0 2000 87
Ohms 0 4000 n/a
MA 4 20 mA 4 20 100
MA 0 20 mA 0 20 99
MV 0 10 mV 0 10 88
MV 0 50 mV 0 50 92
MV 0 100 mV 0 100 95
MV -10 10 mV -10 10 89

Honeywell HC900 Specifications

General

Series	HC900
Redundancy	Optional
Programming Language	Function Block Diagram, Ladder Logic, Structured Text
Inputs	Analog, Digital
Outputs	Analog, Digital, Relay
Display	Optional
Control	PID, Advanced Control
Power Supply	24V DC or 100-240V AC
Storage Temperature	-40°C to 85°C
Humidity	5% to 95% non-condensing
Communication Protocols	Modbus, Ethernet
