AC Power Supply Selection for racks with I/O
To determine which I/O rack AC power supply to use (P01 or P02), calculate power requirements below.
ATTENTION
Using inadequate power supply will cause the controller to cycle power on and off.
A B C D E
Module type
Enter
Quantity
Max
Current @
5 V
Max
Current @
24 V
Calculate 5V current
( D = A * B )
Calculate 24V current
( E = A * C )
Controller (C30 and C30S) ( ) 820 mA 0 mA ( ) ( 0 )
Controller (C50 and C50S) ( ) 930 mA 0 mA ( ) ( 0 )
Controller (C70 and C70S) ( ) 1150 mA 0 mA ( ) ( 0 )
Controller (C75) ( ) 1500 mA 0 mA ( ) ( 0 )
Scanner 1 Port ( ) 670 mA 0 mA ( ) ( 0 )
Scanner 2 Port ( ) 770 mA 0 mA ( ) ( 0 )
Power Status Module (PSM) ( ) 22 mA 0 mA ( ) ( 0 )
Analog Input (8 pts) ( ) 40 mA 25 mA ( ) ( )
Analog Input (16 pts) ( ) 75 mA 50 mA ( ) ( )
Analog Output (4 pts)* ( ) 40 mA 200 mA ( ) ( )
Analog Output (8 pts) ( ) 225 mA 350 mA ( ) ( )
Analog Output (16 pts) ( ) 350 mA 700 mA ( ) ( )
AC Digital Input (16 pts) ( ) 130 mA 0 mA ( ) ( 0 )
DC Digital Input (16 pts) ( ) 130 mA 0 mA ( ) ( 0 )
AC/DC Digital Input (16 pts) ( ) 130 mA 0 mA ( ) ( 0 )
Contact Input (16 pts) ( ) 130 mA 40 mA ( ) ( )
DC Digital Input (32 pts) ( ) 215 mA 0 mA ( ) ( 0 )
AC Digital Output (8 pts) ( ) 220 mA 0 mA ( ) ( 0 )
DC Digital Output (16 pts) ( ) 340 mA 0 mA ( ) ( 0 )
DC Digital Output (32 pts) ( ) 235 mA 0 mA ( ) ( 0 )
Relay Output (8 pts) ( ) 110 mA 100 mA ( ) ( )
Pulse/Frequency/Quadrature** ( ) 110 mA 250 mA ( ) ( )
*Limit 10 Analog Output modules per I/O rack.
** Limit 4 PFQ modules per I/O rack.
Total mA @ 5V =
( )
Total mA @ 24V=
( )
Complete columns A, D and E above.
1. Is column D total mA @ 5V less than 2000mA? Yes/No
2. Is column E total mA @ 24V less than 900mA? Yes/No
3. If the answers to 1 and 2 are YES, go to 4. If the answer to 1 or 2 is NO, use power supply 900P01-0001.
4. Multiply Total mA @ 5V total by 5.1 ( )
5. Multiply Total mA @ 24V total by 24.5 ( )
6. Sum results of 4 and 5. ( )
7. Divide results of 6 by 1000 ( )
8. Is the result of 7 less than 28? Yes/No
9. If the answer to 8 is Yes, use power supply 900P02-0001
10. If the answer to 8 is No, use power supply 900P01-0001
