Specifications - General Specifications
Revision 19 HC900 Process Controller Installation and User Guide 199
06/14
Approvals
CE Conformity
This product is in conformity with the protection requirements of the following European
Council Directives: 2006/95/EC, the Low Voltage Directive, and 2004/108/EC
, the EMC Directive. Conformity of this product with any other “CE Mark” Directive(s) shall not
be assumed. EN61326: Electrical Equipment For Measurement, Control and Laboratory use.
EMC requirements.
ATEX
The apparatus fulfills the requirements for Group II, Category 3 equipment in accordance with
Directive 94/9/EC.
ABS Type Approval
Certificate of Design Assessment - 06-HS186538-4-PDA (June 2014.)
No. 06-BA766694-X (York Location)
No. BY1100081X (Pune Location)
General Purpose
Safety
Compliant with EN61010-1, UL, UL 61010-1 2
nd
edition, CSA C22.2 No. 1010-1
Hazardous
(Classified) Location
Safety
FM Class I, Div. 2, Groups A, B, C, D
CSA Class I, Div. 2 Groups A, B, C, D
Class 1, Zone 2, IIC
Module Temperature
Classifications
Module Type
“T”
Rating
Module Type
“T”
Rating
Redundant CPU Rack
T6
Scanner 2 Port
T4
Redundant PS Ext. Rack
T5
Analog Input (8 channels)
T6
8 Slot Redundant PS Ext. Rack
T6
Analog Input (16 chan)
T6
12 Slot Redundant PS Ext. Rack
T6
Analog Output (4 chan)
T4
4 I/O Slot Rack
T6
Analog Output (8 chan)
T4
8 I/O Slot Rack
T6
Digital Input, Contact type (16 chan)
T5
12 I/O Slot Rack
T6
Digital Input, 24 Vdc (16 chan)
T4
Power Supply (P01)
T4
Digital Input, 120/240 Vac (16 chan)
T3C@ Ta= 60 deg. C
T4 @ Ta = 40 deg. C
Digital Input 120/240VAC, 125VDC
(16 Channel)
T3@Ta=60 deg. C
T4@Ta=40 deg. C
Power Supply (P02)
T4
Digital Input Vdc (32 chan)
T3@Ta=60 deg. C
T4@Ta=40 deg. C
Power Supply (P24)
T4
Digital Output, Relay type (8 chan)
T5
Power Status Module (PSM)
T6
Digital Output, 24 Vdc, (16 chan)
T4
C30/C50/C70/C75 CPU
T4
Digital Output, 120/240 Vac (* chan)
T4
Redundancy Switch Module (RSM)
T6
Digital Output Vdc (32 chan)
T6
Scanner 1 Port
T4
Pulse/Frequency/Quadrature (4 chan)
T5
Environmental Conditions
Ambient
Temperature
Reference
Rated
Extreme
Transportation & Storage
F
C
77+/-5
25+/-3
32 to 140
0 to 60
32 to 140
0 to 60
-40 to 158
-40 to 70
Ambient Relative
Humidity
*45 % to 55 % RH
non-condensing
*10% to 90 % RH
non-condensing
*5 % to 90 % RH
non- condensing
*5 % to 95 % RH
non-condensing
Mechanical
Acceleration
Duration
0 g
0 ms
1 g
30 ms
1 g
30 ms
Not rated
Vibration
0 Hz
0 g
0 Hz to 14 Hz—
amplitude 2.5 mm
(peak-to-peak)
14 Hz to 250 Hz—
acceleration 1 g
0 Hz to 14 Hz—
amplitude 2.5 mm
(peak-to-peak)
14 Hz to 250 Hz—
acceleration 1 g
* Applies up to 40C

Honeywell HC900 Specifications

General

Series	HC900
Redundancy	Optional
Programming Language	Function Block Diagram, Ladder Logic, Structured Text
Inputs	Analog, Digital
Outputs	Analog, Digital, Relay
Display	Optional
Control	PID, Advanced Control
Power Supply	24V DC or 100-240V AC
Storage Temperature	-40°C to 85°C
Humidity	5% to 95% non-condensing
Communication Protocols	Modbus, Ethernet
