Power Sweep
Function Group
Menu Map
Description
Programming Codes
See Also
POWER
5
This softkey enables the power sweep function. RF output power
can be swept both positively and negatively over a selected range.
The level of the power sweep starting point is the power level
programmed. Power sweep widths can be 45 dB wide in either
direction. However, the
settable
power sweep range is dependent on
the ALC level set. An asterisk next to the key label indicates that
this feature is active.
SCPI:
POWer:MODE
SWEeplFIXed
POWer:STARt <num>[level suffix]]MAXimum]MINimum
POWer:SPAN <num>[level suffix]]MAXimum]MINimum
Analyzer:
PSl
function on, PSO function off.
[POWER
LEVEL), Power Slope
“Power Sween and Power Slone
Oneration”
in Chanter 1
P-8 Operating and Programming Reference
