Acceptable range during non-oper-
ation
Acceptable range during operationCondition
2.4G p-p, 5-500 Hz at 1.0
octave/minute
1G p-p, 5-500 Hz at 1.0 octave/minuteVibration
None required.350 cu ft/min. (0.00059 cu m/hr)Air flow
Not applicable.
1440 Watts or 4914 BTU (Eight FC8-48
blades and two CP8 blades)
Heat dissipation
Table 51 DC04 SAN Director environmental requirements
Acceptable range during non-oper-
ation
Acceptable range during operationCondition
-40° to +70° C outside switch (-40° to
158° F)
10° to 40° C outside switch (50° to 104° F)
Ambient temperat-
ure
10% to 93% RH noncondensing, at
70° Celsius
5% to 85% RH noncondensing, at 40° Celsius,
with maximum gradient of 10% per hour
Humidity
0 to 12 km (40,000 ft.) above sea
level
Up to 3 km (10,000 ft.) above sea levelAltitude
33G, 11ms duration, half-sine wave20G, 6ms duration, half-sine waveShock
2.0G p-p, 5-500 Hz at 1.0
octave/minute
0.5G p-p, 5-500 Hz at 1.0 octave/minuteVibration
None required.350 cu ft/min. (0.00059 cu m/hr)Air flow
Not applicable.
841 Watts or 2869 BTU/hr (Four FC8-48
blades, two CP8 blades, and two CR4S-8
blades)
Heat dissipation
NOTE:
The 10° to 40° Celsius range applies to the ambient air temperature at the air intake vents on the
non-port side of the DC SAN Director or DC04 SAN Director. The temperature inside the product
chassis can be up to 75° Celsius during operation. If the internal temperature range exceeds the
operating ranges of the components, the LEDs, error messages, and Fabric Watch alerts will indicate
a problem. Use the tempShow command or Fabric Watch commands to view temperature status.
Fibre Channel port specifications
The Fibre Channel ports in the DC SAN Director and DC04 SAN Director support full duplex link
speeds at 10.51875, 8.50, 4.25, 2.125, or 1.0625 Gb/s inbound and outbound, automatically
negotiating to the highest common speed of all devices connected to the port.
The ports are compatible with optical SWL (short wavelength: approximately 850 nm), optical LWL
(long wavelength: approximately 1310 nm), and Extended Long Wavelength (ELWL) laser transmitter
SFPs and XFPs (FC10-6 only) (approximately 1550 nm). The strength of the signal is determined by
the type of SFP or XFP in use.
Technical specifications220
