Items requiredTime estim-
ate
Installation task
Power cables and serial cable (provided in the DC04
SAN Director accessory kit)
20 minutesInstalling power cables and
powering on the DC04 SAN Dir-
ector
SFP optical transceivers30 minutesInstalling SFPs
Fiber optic cables and cable ties60 minutesAttaching fiber optic cables, cable
ties, and cable guides
Serial cable (provided in the DC04 SAN Director
accessory kit)
Workstation computer with a serial port or terminal
server port and a terminal emulator application (such
as HyperTerminal)
Ethernet IP addresses for the DC04 SAN Director
20 minutesEstablishing serial connection,
logging on to DC04 SAN Direct-
or, and configuring IP addresses
Ethernet cabling (optional) for Telnet access. All other
configuration parameters optional. Refer to the HP
StorageWorks Fabric OS 6.2.x administrator guide
for Port Identifier (PID) information.
20 minutesInstalling Ethernet cable(s) and
configuring the DC04 SAN Direct-
or name, policies, domain ID,
PIDs, date and time and addition-
al system parameters
Site preparation, unpacking the DC04 SAN Director
IMPORTANT:
See “Regulatory compliance and safety notices” on page 229 for important safety guidelines before
setting up your DC04 SAN Director.
The following steps are required to ensure correct installation and operation:
1. Provide a space that is 9 rack units (9U) high, 61.19 cm (24.09 in.) deep, and 43.74 cm (17.22
in.) wide. 1U is equal to 4.45 cm (1.75 in.)
2. The DC04 SAN Director can be installed facing in either direction, provided that serviceability
and cooling requirements are met.
3. Plan for cable management before installing the chassis.
Cables can be managed in a variety of ways, such as by routing cables below the chassis, to
either side of the chassis, through cable channels on the sides of the cabinet, or by using patch
panels (see “Managing cables” on page 139).
DC04 SAN Director Installation126
