Figure 12 Inter-chassis link (ICL) connections (configuration 2)
2. Core switch blades (CR8)1. Chassis 1
4. Port blades3. Core Processor blades (CP8)
6.ICL connector (ICL 0)5. ICL connector (ICL 1)
8. Chassis 27. ICL cables
DC SAN Director Installation46
