Page #47 background image
26374a
1
2
3
4
5
6
7
8
Figure 13 Inter-chassis link (ICL) connections (configuration 3)
2. Core switch blades (CR8)1. Chassis 1
4. Port blades3. Core Processor blades (CP8)
6.ICL connector (ICL 0)5. ICL connector (ICL 1)
8. Chassis 27. ICL cables
HP StorageWorks DC and DC04 SAN Backbone Director Switches 47
