Size and weightSystem
25.76 kg (56.8 lb.)Empty chassis:
• No blades
• No CP blade
• No core switch blade
• No power supplies
• No fan assemblies
System blade and FRU weights
Table 46 System FRU weights
WeightFRU
3.0 kg (6.6 lb.)CP blade (CP8)
3.27 kg (7.2 lb.)CR blade (CR8, CR4S-8)
3.0 kg (6.6 lb.) without mediaFC8-16 port blade
3.27 kg (7.2 lb.) without mediaFC8-32 port blade
3.36 kg (7.4 lb.) without mediaFC8-48 port blade
3.1 kg (6.8 lb) without mediaFC10-6 port blade
3.36 kg (7.4 lb) without mediaFR4-18i application blade
1.5 kg (3.2 lb)Port card filler panel
2.45 kg (5.4 lb.)Power supply
5.73 kg (12.6 lb.)Blower assembly
0.3 kg (0.6 lb)WWN bezel
0.45 kg (1.0 lb.)
0.45 kg (1.0 lb.)
Cable management comb (DC SAN Director)
Vertical cable management fingers (DC04 SAN
Director)
0.3 kg (0.6 lb.)WWN bezel
2.09 kg (4.6 lb.)Chassis door
Facility requirements
The facility where the product is in use must meet the following requirements to provide for correct
operation:
• Adequate supply circuit, line fusing, and wire size, as specified by the electrical rating on the
chassis nameplate
• An air flow of at least 350 cubic feet per minute (595 cubic meters per hour) in the immediate
vicinity of the DC SAN Director or DC04 SAN Director
Technical specifications214
