Non-port side of the DC SAN Director
Figure 2 displays a sample configuration of the non-port side view of the DC SAN Director.
25370a
2
3
1
Figure 2 Non-port side of the DC SAN Director (sample configuration)
2. Power supply1. WWN bezel (logo plate)
3. Blower assembly
HP StorageWorks DC SAN Backbone Director Switch Overview22
